Κωδικός προϊόντος: 6761348
Screw clamp boring bar for holding a 75° rhombic shape positive insert with an inscribed circle diameter 5.56mm, 2.38mm thick (ISO designation EP.. 0502.. ), right hand 95° side and end cutting with off-set shank, steel without coolant hole, 6mm diameter 25mm protrusion length for cone boring and lo..
Κωδικός προϊόντος: 6760482
Screw clamp boring bar for holding a triangle shape positive insert with an inscribed circle diameter 3.97mm, 1.98mm thick (ISO designation TC.. 06T1.. ), right hand 90° end cutting with off-set shank, steel without coolant hole, 6mm diameter 25mm protrusion length for cone boring and longitudinal b..
Κωδικός προϊόντος: 6761347
Screw clamp boring bar for holding a 75° rhombic shape positive insert with an inscribed circle diameter 5.56mm, 2.38mm thick (ISO designation EP.. 0502.. ), right hand 95° side and end cutting with off-set shank, steel without coolant hole, 6mm diameter 46mm protrusion length for cone boring and lo..
Κωδικός προϊόντος: 6760715
Screw clamp boring bar for holding a 80° rhombic shape positive insert with an inscribed circle diameter 6.35mm, 2.38mm thick (ISO designation CC.. 0602.. ), right hand 95° side and end cutting with off-set shank, steel without coolant hole, 8mm diameter 35mm protrusion length for cone boring and lo..
Κωδικός προϊόντος: 6760719
Screw clamp boring bar for holding a 80° rhombic shape positive insert with an inscribed circle diameter 6.35mm, 2.38mm thick (ISO designation CC.. 0602.. ), right hand 95° side and end cutting with off-set shank, steel without coolant hole, 8mm diameter 50mm protrusion length for cone boring and lo..
Κωδικός προϊόντος: 6760720
Screw clamp boring bar for holding a 80° rhombic shape positive insert with an inscribed circle diameter 6.35mm, 2.38mm thick (ISO designation CC.. 0602.. ), right hand 95° side and end cutting with off-set shank, steel without coolant hole, 10mm diameter 54mm protrusion length for cone boring and l..
Κωδικός προϊόντος: 6760721
Screw clamp boring bar for holding a 80° rhombic shape positive insert with an inscribed circle diameter 6.35mm, 2.38mm thick (ISO designation CC.. 0602.. ), right hand 95° side and end cutting with off-set shank, steel without coolant hole, 12mm diameter 64mm protrusion length for cone boring and l..
Κωδικός προϊόντος: 6760722
Screw clamp boring bar for holding a 80° rhombic shape positive insert with an inscribed circle diameter 9.525mm, 3.97mm thick (ISO designation CC.. 09T3.. ), right hand 95° side and end cutting with off-set shank, steel without coolant hole, 16mm diameter 74mm protrusion length for cone boring and ..
Εμφάνιση 1 έως 8 από 8 (1 Σελ.)
