Κωδικός προϊόντος: 7174105
Thread forming tap with lube grooves with chamfer form C with a 2-3xP plug lead, for Unified National Coarse thread UNC 4 with 40 TPI and 2BX class of fit, dimensions according to DIN 2184-1 standard with 3.5mm shank and 2.7mm square drive, cobalt based HSS-E with TiN coating for 3.5xD through or bl..
Κωδικός προϊόντος: 7174110
Thread forming tap with lube grooves with chamfer form C with a 2-3xP plug lead, for Unified National Coarse thread UNC 5/16" with 18 TPI and 2BX class of fit, dimensions according to DIN 2184-1 standard with 8.0mm shank and 6.2mm square drive, cobalt based HSS-E with TiN coating for 3.5xD through o..
Κωδικός προϊόντος: 7174106
Thread forming tap with lube grooves with chamfer form C with a 2-3xP plug lead, for Unified National Coarse thread UNC 6 with 32 TPI and 2BX class of fit, dimensions according to DIN 2184-1 standard with 4.0mm shank and 3.0mm square drive, cobalt based HSS-E with TiN coating for 3.5xD through or bl..
Κωδικός προϊόντος: 7174112
Thread forming tap with lube grooves with chamfer form C with a 2-3xP plug lead, for Unified National Coarse thread UNC 7/16" with 14 TPI and 2BX class of fit, dimensions according to DIN 2184-1 standard with 8.0mm shank and 6.2mm square drive, cobalt based HSS-E with TiN coating for 3.5xD through o..
Κωδικός προϊόντος: 7174107
Thread forming tap with lube grooves with chamfer form C with a 2-3xP plug lead, for Unified National Coarse thread UNC 8 with 32 TPI and 2BX class of fit, dimensions according to DIN 2184-1 standard with 4.5mm shank and 3.4mm square drive, cobalt based HSS-E with TiN coating for 3.5xD through or bl..
Κωδικός προϊόντος: 7174102
Thread forming tap with chamfer form C with a 2-3xP plug lead, for ISO-Metric Fine thread M10 with 1.00 mm pitch and 6HX class of fit, dimensions according to DIN 2174 standard with 7.0mm shank and 5.5mm square drive, cobalt based HSS-E with TiN coating for 3xD through or blind hole threading in fre..
Κωδικός προϊόντος: 7174103
Thread forming tap with chamfer form C with a 2-3xP plug lead, for ISO-Metric Fine thread M10 with 1.25 mm pitch and 6HX class of fit, dimensions according to DIN 2174 standard with 7.0mm shank and 5.5mm square drive, cobalt based HSS-E with TiN coating for 3xD through or blind hole threading in fre..
Κωδικός προϊόντος: 7174104
Thread forming tap with chamfer form C with a 2-3xP plug lead, for ISO-Metric Fine thread M12 with 1.50 mm pitch and 6HX class of fit, dimensions according to DIN 2174 standard with 9.0mm shank and 7.0mm square drive, cobalt based HSS-E with TiN coating for 3xD through or blind hole threading in fre..
Κωδικός προϊόντος: 7174100
Thread forming tap with chamfer form C with a 2-3xP plug lead, for ISO-Metric Fine thread M6 with 0.75 mm pitch and 6HX class of fit, dimensions according to DIN 2174 standard with 6.0mm shank and 4.9mm square drive, cobalt based HSS-E with TiN coating for 3xD through or blind hole threading in free..
Κωδικός προϊόντος: 7174101
Thread forming tap with chamfer form C with a 2-3xP plug lead, for ISO-Metric Fine thread M8 with 1.00 mm pitch and 6HX class of fit, dimensions according to DIN 2174 standard with 6.0mm shank and 4.9mm square drive, cobalt based HSS-E with TiN coating for 3xD through or blind hole threading in free..
Κωδικός προϊόντος: 7174067
Thread forming tap with lube grooves with chamfer form C with a 2-3xP plug lead, for ISO-Metric thread M10 with 1.50 mm pitch and 6HX class of fit, dimensions according to DIN 2174 standard with 10.0mm shank and 8.0mm square drive, cobalt based HSS-E with TiN coating for 3.5xD through or blind hole ..
Κωδικός προϊόντος: 7174068
Thread forming tap with lube grooves with chamfer form C with a 2-3xP plug lead, for ISO-Metric thread M12 with 1.75 mm pitch and 6HX class of fit, dimensions according to DIN 2174 standard with 9.0mm shank and 7.0mm square drive, cobalt based HSS-E with TiN coating for 3.5xD through or blind hole t..
